Guide To Measuring Your Air Filter

It is essential to ensure that the air filter you choose is the correct size for your HVAC system to guarantee proper operation. An improperly fitting filter can negatively affect your system's efficiency, leading to poor air quality and potential health issues for everyone in the household. Additionally, a misfit can result in higher energy costs due to increased strain on your system, along with the accumulation of dust, allergens, and other harmful pollutants that can compromise health and comfort.

In this guide, we will cover everything you need to know about measuring your air filter. You will learn about the various types of air filters available and how to measure one accurately for your HVAC system. We will also discuss how selecting the right size can extend the life of your system and the importance of regular filter maintenance. By the time you finish reading, you will be equipped to choose the correct filter to keep your HVAC system operating at peak performance, improve your air quality, and manage your energy expenses effectively.

Various Kinds Of Air Filters

Choosing a suitable air filter for your HVAC system is crucial for maintaining system efficiency and improving indoor air quality. Various types of air filters are available, each with unique features that cater to different needs. Understanding these options will help you make an informed decision.

1. Pleated Filters: Pleated filters are crafted from folded fabric, typically cotton or polyester, which significantly increases the surface area of the filter. This design allows for greater efficiency in capturing airborne contaminants. The more pleats present, the more effective these filters are at trapping allergens, mildew spores, and pet dander. Although pleated filters tend to be more expensive than fiberglass options, they provide superior air quality and are available in both reusable and disposable forms. Their effectiveness makes them a solid choice for homes with allergy sufferers or pets.

2. Fiberglass Filters: Fiberglass filters, often referred to as flat-paneled filters, are made from spun glass fibers held in place by a metal frame. Their affordability makes them a popular choice among consumers. However, they primarily capture larger particles like dust and pollen, doing little to enhance overall indoor air quality. While they may be budget-friendly, those looking for significant filtration may want to consider alternatives.

3. HEPA Filters: HEPA (High-Efficiency Particulate Air) filters are among the most effective options for removing airborne particles. Capable of eliminating up to 99.97% of contaminants—including germs, viruses, mold, dust, and pollen—these filters excel in environments where clean air is essential. Although they often come with a higher price tag, HEPA filters are highly beneficial for individuals with respiratory issues or severe allergies. Their performance justifies the investment, particularly in settings such as hospitals or homes with vulnerable residents.

4. Electrostatic Filters: Electrostatic filters utilize a combination of paper fibers and cotton to generate a static charge that attracts and captures particles as they pass through. These filters are available in flat and pleated styles, as well as washable and disposable varieties. They are particularly well-suited for those with allergies, as their static charge enhances their ability to trap fine particles, including pet dander and dust.

5. UV Light Filters: UV light filters leverage ultraviolet light to kill viruses and bacteria in the air, making them a valuable addition to your home’s air purification system. However, they are not designed to remove dust or other particulate matter. For optimal results, UV light filters are often used in conjunction with other types, such as HEPA filters, to provide comprehensive air quality management.

6. Washable Filters: Washable filters can be found in both flat and pleated styles and are designed for reuse. Although they may require a higher initial investment, they save money in the long run and are environmentally friendly. Regular cleaning is essential to maintain their effectiveness, and it’s crucial to ensure they are completely dry before reinstallation to prevent mold growth.

7. Media Filters: Media filters consist of pleated material sealed in a metal frame, offering a large surface area for capturing particles. These filters are low-maintenance, typically lasting about two years, and are seven times more efficient than standard filters. They are especially beneficial for those living in industrial areas or individuals with health concerns who require a higher level of air purification.

Look For Air Filter Measurements On The Side Of The Filter

When selecting or replacing an air filter, it’s essential to check the measurements listed on the side of the filter. Most filters show two sizes along the edge. The larger number, known as the "nominal" size, is a rounded measurement that serves as a general reference and is typically displayed in a larger font. The smaller number, referred to as the "actual" size, provides the precise dimensions of the filter and is usually written in a smaller font. Knowing the exact size of your air filter is crucial for ensuring it fits your HVAC system correctly. Verifying these measurements helps prevent poor-fitting filters, which can reduce system efficiency and negatively impact indoor air quality. Even slight differences in filter size can affect how well your system performs, so always rely on these numbers to choose the correct size.

Air Filter Measurements: Nominal Size vs. Actual Size

It's important to know how to distinguish between nominal and actual sizes when buying new air filters for your HVAC system. Understanding these two measurements ensures that the filter you select fits properly, optimizing system efficiency and maintaining the air quality inside your home.

  • Nominal Size: The nominal size is the filter's approximate measurement, rounded to the nearest inch. This size is typically shown on the filter's packaging, making it easier to identify and choose the right filter. For instance, a filter labeled 18x20x4 refers to a nominal size of 18 inches by 20 inches by 4 inches. Keep in mind that this is a general estimate, and the actual size may differ slightly.
  • Actual Size: The actual size refers to the precise dimensions of the filter. Using a tape measure, you can determine the exact length, width, and thickness of the filter. For example, a filter marked as 18x20x4 may have an actual size of 17.5 by 19.5 by 3.75 inches.
Steps To Measure Your Air Filter Dimensions

Steps To Measure Your Air Filter Dimensions

For best performance and efficiency, make sure your HVAC system has a correct size air filter. Here is a brief guide that will help you precisely measure your air filter:

Step 1: Turn Off Your HVAC System: Turn off your HVAC system first. By doing this, you will be able to work on the filter without worrying about particles getting pulled into the system.

Step 2: Find Your Current Filter: Find out where your air filter is set up. It is usually located in the furnace, air handler unit, or return air grille. It becomes easier to remove it if you know where it is placed.

Step 3: Remove The Existing Filter: Remove the currently installed air filter from its slot with caution. Pay attention to where it is placed, particularly if it includes arrows indicating the direction of the wind.

Step 4: Measure The Filter’s Length And Width: The total length of the filter should be measured from top to bottom using a tape measure. Next, determine the width of each side. Note that these measurements are in inches. You can find a filter that fits properly by using these specifications.

Step 5: Measure The Thickness: At this point, measure the filter's depth or thickness. The measurement indicates the difference between the two sides of the filter. Make sure to record this measurement as well.

Step 6: Double-Check Your Measurements: Check that the measurements you took are correct by reviewing them again. Remember that the sizes of filters are both nominal and actual. For labeling purposes, the nominal size is a rounded number, and the actual size is the exact measurement of the filter.

Step 7: Choose The Right Replacement Filter: Make sure the replacement filter you choose matches the nominal and actual sizes of your existing filter by taking measurements. This makes sure that the air filter works well and fits correctly.

Step 8: Install The New Filter: As you place the replacement filter into the housing, make sure it fits properly and matches with any airflow direction signs. Restart your HVAC system after it's been installed correctly.

Most Common Air Filter Sizes

8x8x1 8x20x2
10x24x3 10x28x1
12x15x1 12x18x2
13x21.5x1 13x25x3
14x14x1 14x22x1
15x30x3 16x22.25x2
16x24x1 18x24x1
18x30x3 20x21x1
20x27x1 24x24x2
25x28x3 30x30x1

Choosing The Right Fit Can Make Your System Last Longer

Choosing a suitable air filter is key to extending the life and enhancing the performance of your HVAC system. A properly sized filter efficiently captures dust, debris, and other particles, allowing the system to run smoothly. This prevents harmful buildup that can strain your system, leading to costly repairs or a shortened lifespan.

A correctly fitted filter also ensures proper airflow, reducing the strain on your system and minimizing energy consumption. By selecting a filter that matches your HVAC system’s requirements, you not only protect your investment but also improve the quality of the air in your home. This helps keep your system running efficiently for years to come.

Ready To Purchase Air Filters

Conclusion

Ensuring that your air filter fits properly is essential for maintaining the efficiency of your heating, ventilation, and air conditioning (HVAC) system. This simple guide will walk you through how to measure your air filter correctly, helping you choose the right size. Getting the correct-sized filter is important not only for maintaining good indoor air quality but also for prolonging the life of your HVAC unit. Be sure to measure carefully, taking into account both the nominal and actual sizes when selecting a new filter for optimal performance.

If you need high-quality HVAC air filters, we can help! At Custom Filters Direct, we offer top-quality filters that provide dependable filtration solutions, keeping your HVAC system in top shape. Contact us today at 1-877-958-5612 to learn more about our products and how they can enhance the efficiency and performance of your home or business HVAC system.

Frequently Asked Questions

Where Can I Find My Air Filter?
Air filters are typically located inside the furnace, within the air handler unit, or in the return air grille. If you're unsure where yours is located, check your HVAC system's manual, which should provide detailed instructions on where to find the filter.
How Is Air Filtration Measured?
Air filtration is measured using MERV, or Minimum Efficiency Reporting Values. This rating indicates the effectiveness of an air filter. A higher MERV rating means the filter is better at capturing smaller particles, such as dust and pollen, and improving air quality. Simply put, the higher the MERV rating, the better the filter’s ability to remove tiny contaminants from the air.
Do I Need An Exact Size Air Filter?
Yes, you need an air filter that fits your HVAC system properly. A filter that doesn’t fit well can allow dust and particles to bypass it and cause your system to work harder. This can lower efficiency and even damage your system. Always choose an air filter that matches your system’s exact size for optimal performance.
How Are Air Filters Tested?
Air filters are tested in a controlled environment where contaminants like smoke, dust, or chemicals are mixed with air. The testers first measure how quickly these particles disperse naturally. They then run the air filter and see how effectively it removes the pollutants. This process measures the filter’s air purification efficiency.
What Should I Do If My Measurements Don’t Match Standard Filter Sizes?
If your air filter measurements don’t match standard sizes, you may need a custom filter. Some companies, like Custom Filters Direct, create filters for non-standard sizes. Contact them to discuss a personalized solution that ensures your filter fits and works correctly.
How Often Should I Replace My Air Filter?
The frequency of replacing your air filter depends on the type of filter, your usage, and your environment. Typically, filters should be replaced every one to three months. However, check your filter regularly and replace it if it looks clogged or dirty. Regular filter changes help maintain HVAC efficiency and improve indoor air quality.
Does The Airflow Direction Matter When Installing A New Filter?
Yes, the airflow direction is important. Most filters have an arrow on the body that indicates the correct airflow direction. Installing the filter in the wrong direction can reduce efficiency and even damage your system. Always follow the arrow to ensure the filter is installed correctly for optimal performance.
What Should I Do If I’m Still Unsure About Measuring My Air Filter?
If you are still unsure about measuring your air filter, it’s a good idea to consult an HVAC professional. You can also reach out to a trusted supplier like Custom Filters Direct for expert advice. They can help ensure you select the right size and type of filter for your system.
